BATRAZZI Aluminum Upper Lower Chassis Link Set for SCX30

BATRAZZI Aluminum Upper Lower Chassis Link Set for SCX30 (Black)

Lightweight Precision. Enhanced Suspension Control.
CNC machined from high-quality aluminum alloy, these chassis links provide a strong and precise suspension connection for improved handling on technical terrain.

The lightweight design helps maintain chassis agility while delivering increased rigidity and more consistent suspension movement. With improved structural stability, the links provide better control during articulation, side-hilling, and challenging crawling conditions.
Finished with a durable anodized coating, they combine performance, protection, and a premium factory-style appearance.

Features:
1. Precision CNC machined from aluminum alloy
2. Lightweight construction with increased rigidity
3. Improves suspension consistency and chassis control
4. Enhances articulation performance on technical trails
5. Durable anodized finish for long-lasting protection

Specifications
Compatible with: SCX30

Front Upper Chassis Link: 3*2.5*34mm, 0.5g/pc
Rear Upper Chassis Link: 4.5*2.5*44.38mm, 0.7g/pc
Front Lower Chassis Link: 4*2.5*39.5mm, 0.6g/pc
Rear Lower Chassis Link: 9*2.5*48.86mm, 0.8g/pc

Material: Aluminum
Color: Anodized Black

What's in the Pack?
Option 1:
Aluminum front upper link x 2
Aluminum rear upper link x 2
SS ball head( Dia3*3.2) x 6
Ball Stud (Dia3*11.75) x 2
Ball Stud (Dia3*7.4) x 2
O-ring (Dia3.1*0.8) x 20
Screw (PM1.0*6) x 3
Screw (PM1.0*8) x 3

Option 2:
Aluminum front lower link x 2
Aluminum rear lower link x 2
SS ball head( Dia3*3.2) x 6
Ball Stud (Dia3*10.6) x 4
O-ring (Dia3.1*0.8) x 20
Screw (PM1.0*6) x 3
Screw (PM1.0*8) x 3

Option 3:
Aluminum front upper link x 2
Aluminum rear upper link x 2
Aluminum front lower link x 2
Aluminum rear lower link x 2
SS ball head( Dia3*3.2) x 10
Ball Stud (Dia3*10.6) x 4
Ball Stud (Dia3*11.75) x 2
Ball Stud (Dia3*7.4) x 2
O-ring (Dia3.1*0.8) x 40
Screw (PM1.0*6) x 8
Screw (PM1.0*8) x 8

Tools Required for Installation
Phillips screwdriver ; 0.05“ hex screwdriver
